Edge Switch 2/24 installation guide 83
The OSMS view is displayed (Figure 51).
Figure 51 OSMS view
2. Click the Enable or Disable button to enable or disable the OSMS.
3. Select the Enable Host Control check box to enable host control of the product.
NOTE: Before you can enable host control state, OSMS must be enabled.
4. Click OK.
The following message is displayed:
Your changes have been successfully activated
Configuring SSL encryption
SSL is a protocol that encrypts internet communications. The protocol uses key encryption and
includes a digital certificate that enables server authentication and SSL session initialization. To
configure SSL encryption:
1. Select Configure > SSL.
