Using the HAFM Basic interface74

TIP: Use the Windows vertical scroll bar to display additional port information rows.

3. Click Default to select the default values.

A confirmation message is displayed.

4. Click OK to accept the default values.

NOTE: HP recommends that you use the default values. If they are not appropriate, you can

enter values in the RX BB Credit box.

NOTE: If you want to select another port, enter the port number in the Jump to Port box and

then click go.

5. Click OK to save the changes.

6. Place the port back online (see ”Setting the Edge Switch offline and online” on page 71).

Configuring Edge Switch identification

Perform this procedure to configure the Edge Switch name, description, location, and contact

person. The Name, Location, and Contact variables configured here correspond respectively to

the SNMP variables sysName, sysLocation, and sysContact. These variables are used by

SNMP management workstations when obtaining data from managed switches.

To configure the Edge Switch identification:

1. Select Configure > Switch > Identification.

The Identification view is displayed (Figure 44).

Figure 44 Identification view

a. Enter an Edge Switch name of 24 or fewer alphanumeric characters in the Name box.

Each Edge Switch should be configured with a unique name.
