Edge Switch 2/24 installation guide 67
8. Double-click the port connector used to make this ISL connection to open the Port Properties
dialog box (Figure 40).
Figure 40 Port Properties dialog box
9. Ensure that the Link Incident box displays None and the Reason box is blank.
If an ISL segmentation or other problem is indicated, see the Edge Switch service manual to isolate
the problem. If no problems are indicated, installation tasks are complete.
NOTE: If the Open Trunking feature is installed, an additional box (Congested Threshold %) is
displayed in the Port Properties dialog box. This box displays the active congested threshold
percentage currently configured in the Configure Open Trunking dialog box. For more information
about Open Trunking, see the HP StorageWorks Edge Switch Element Manager user guide.
