16.At the Hardware view, select Maintenance > Enable E-Mail Notification.

A check mark is displayed in the check box to indicate e-mail notification for the Edge Switch is

enabled, and the menu closes.

NOTE: Using HAFM, enable or disable e-mail event notification for each Edge Switch

individually.

Configuring and enabling call-home features

There are two call-home features available, and only one is installed when the HAFM application is

installed on the HAFM appliance. To learn more about configuring call-home features, see the HP

StorageWorks HA-Fabric Manager Appliance installation guide.

Configuring and enabling Ethernet events

Perform this procedure to configure and enable Ethernet events. An Ethernet event is recorded (after

a user-specified time interval) when the Edge Switch-to-HAFM appliance communication link drops.

1. Minimize the Hardware view and return to the HAFM application.

2. At the HAFM or HAFM Basic main window, select the Monitor > Ethernet Event.

The Configure Ethernet Events dialog box is displayed (Figure 28).

Figure 28 Configure Ethernet Events dialog box

3. Select the Enable Ethernet Events check box.

A check mark is displayed in the check box to indicate Ethernet events are enabled.

4. Enter a value from 10 through 120 minutes in the Ethernet Timeout box.

5. Click OK to close the dialog box.

Configuring, enabling, and testing call-home event notification

Telephone numbers and other information for the call-home feature are configured through the

Windows 2000 dial-up networking application. See ”Configuring and enabling call-home features”

on page 55 for configuration information. To configure, enable, and test call-home event

notification:

1. Minimize the Hardware view and return to the HAFM application.
