Edge Switch 2/24 installation guide 41

4 Using HAFM to configure the Edge Switch

This chapter tells you how to use HAFM to perform the most common configuration tasks for the

Edge Switch 2/24:

NOTE: For a complete reference on HAFM functionality, see the HP StorageWorks HA-Fabric

Manager user guide.

• Setting the Edge Switch online and offline, page 41

• Configuring Edge Switch identification, page 42

• , page 43

• Configuring fabric operating parameters, page 46

• Configuring switch binding, page 48

• Configuring preferred path, page 48

• Configuring ports, page 49

• Configuring SNMP trap message recipients, page 52

• Configuring, enabling, and testing e-mail notification, page 52

• Configuring and enabling call-home features, page 55

• Configuring and enabling Ethernet events, page 55

• Configuring, enabling, and testing call-home event notification, page 55

• Threshold alerts, page 56

• Configuring SANtegrity Authentication, page 62

• Backing up HAFM configuration data, page 63

• Resetting configuration data, page 63

• Enabling the HAFM Basic interface, page 65

• Enabling Telnet, page 65

• Connecting the Edge Switch to a fabric, page 65

Setting the Edge Switch online and offline

When the Edge Switch is set online, an attached device can log in to the Edge Switch if the port is

not blocked. Attached devices can communicate with each other if they are configured in the same

zone.

When the Edge Switch is set offline, all ports are set offline. The Edge Switch transmits the offline

sequence (OLS) to attached devices, and the devices cannot log in to the Edge Switch.
