Introduction to the Edge Switch 2/2422
Optional kits
Contact your HP-authorized service provider to purchase optional Edge Switch 2/24 kits described
in Table 2.
Table 2 Edge Switch 2/24 optional kits
Supporting Kit Description
8-flexport upgrade for Edge Switch 2/24
Part Number: 316096-B21
Used to upgrade the Edge Switch 2/24 from:
8 to 16 ports
16 to 24 ports
Edge Switch 2/24 Product Manager license
Part Number: 317067-B21
Used when switch is managed through HAFM
HP Open Trunking license
Part Number: 336002-B21
Provides a license to use the Open Trunking
feature
HP SANtegrity Binding license
Part Number: 317073-B21
Provides a license to use the SANtegrity
Binding feature
300m Optical Transceiver Kit
Part Number: 300834-B21
Provides short-wave optical transceiver for the
Edge Switch 2/24
10km Long Distance Optical Transceiver Kit
Part Number: 300835-B21
Provides 10 km long-wave optical transceiver
for the Edge Switch 2/24
35 km Extended Reach Optical Transceiver Kit
Part Number: 300836-B21
Provides 35 km long-wave optical transceiver
for the Edge Switch 2/24
