Edge Switch 2/24 installation guide 119
Laser information
Three configurations of cards with fixed optics are provided for each of the connector types: four
extended long-wave ports, four long-wave ports, and four short-wave ports.
se
Table 10 Laser specifications—2 Gb
Part number Transceivers on
UPM card
Wave
length
Media/
distance
Standard
300836-B21
Long-wave —
35 km
4 Extended
long-wave
1310 nm 9/125 μm
Single mode:
1 m–35 km
100-SM-LL-L
300835-B21
Long-wave —
10 km
4 long-wave 1310 nm 9/125 μm
Single mode:
1 m–10 km
100-SM-LL-L
300834-B21
Short-wave
4 short-wave 850 nm 50/125 μm
Multimode:
2 m–500 m
62.5/125 μm
Multimode:
1 m–200 m
100-M5-SN-I
