Technical specifications116
Ports Port Names NULL strings
Port Blocked States Unblocked
FAN Enabled
LIN Alerts Enabled
Ports enabled 8
Switch addressing IP Address 10.1.1.10
Subnet Mask 255.0.0.0
Gateway Address 0.0.0.0
MAC Address PROM value
Operating mode Must select one of two modes:
Open Fabric 1.0 or
Homogeneous. HP
recommends using the Open
Fabric 1.0 mode.
Open Fabric 1.0 mode
Operating
parameters
Preferred Domain ID 1
Insistent Domain ID
Disabled
R_A_TOV 10 seconds (100 tenths)
E_D_TOV 2 seconds (20 tenths)
Switch Priority Default
Switch Speed 2 Gbps
Rerouting Delay Enabled
Domain RSCNs Disabled
Suppress RSCNs on Zone set
activations
Disabled
SNMP SNMP Communities “public” — 5 NULL strings
SNMP Write Authorizations Read only per community
Trap Recipient IP Addressees 0 for each
UDP Port 162
SNMP Authorization Trap State Disabled
Table 5 Switch factory-default values for reset configuration option (continued)
Configuration
catagory
Description Default
