Edge Switch 2/24 installation guide 115
B Technical specifications
This appendix contains the following information:
• Factory defaults, page 115
• Physical dimensions, page 117
• Environmental specifications, page 117
• Power requirements, page 118
• Operating tolerances, page 118
• Laser information, page 119
Factory defaults
Table 4 lists the defaults for the passwords, and IP, subnet, and gateway addresses.
Table 5 provides the Edge Switch factory-default values for the reset configuration option.
Table 4 Factory-set defaults
Item Default
User name
(case-sensitive) Administrator
Customer password
(case-sensitive)
password
Maintenance password
(case-sensitive)
level-2
IP address 10.1.1.10
Subnet mask 255.0.0.0
Gateway address 0.0.0.0
Table 5 Switch factory-default values for reset configuration option
Configuration
catagory
Description Default
Identification Switch Name NULL string
Switch Description “Fibre Channel Switch”
Switch Contact “End User Contact (please
configure)”
Switch Location “End User Contact (please
configure)”
