Regulatory compliance and safety104
WARNING! Your computer contains an internal lithium manganese dioxide, a vanadium
pentoxide, or an alkaline battery pack. There is risk of fire and burns if the battery pack is not
properly handled. To reduce the risk of personal injury:
• Do not attempt to recharge the battery.
• Do not expose to temperatures higher than 60°C.
• Do not disassemble, crush, puncture, short external contacts, or dispose of in fire or water.
• Replace only with the HP spare part designated for this product.
For more information about battery replacement or proper disposal, contact an HP-authorized
reseller or service provider.
Taiwan battery recycling notice
Power cords
The power cord set must meet the requirements for use in the country where the product was
purchased. If the product is to be used in another country, purchase a power cord that is approved
for use in that country.
The power cord must be rated for the product and for the voltage and current marked on the product
electrical ratings label. The voltage and current rating of the cord should be greater than the voltage
and current rating marked on the product. In addition, the diameter of the wire must be a minimum
of 1.00 mm
2
or 18 AWG, and the length of the cord must be between 1.8 m (6 ft) and 3.6 m
(12 ft). If you have questions about the type of power cord to use, contact an HP-authorized service
provider.
NOTE: Route power cords so that they will not be walked on and cannot be pinched by items
placed upon or against them. Pay particular attention to the plug, electrical outlet, and the point
where the cords exit from the product.
Batteries, battery packs, and accumulators should not be disposed of together
with the general household waste. To forward them to recycling or proper
disposal, please use the public collection system or return them to HP, an
authorized HP Partner, or their agents.
The Taiwan EPA requires dry battery manufacturing or importing
firms in accordance with Article 15 of the Waste Disposal Act to
indicate the recovery marks on the batteries used in sales,
giveaway or promotion. Contact a qualified Taiwanese recycler
for proper battery disposal.
