Edge Switch 2/24 installation guide 9
About this guide
This guide provides information about:
• Installing the Edge Switch 2/24
• Performing initial configuration of the switch
Intended audience
This guide is intended for use by administrators who are familiar with the following:
• Fibre Channel technology
• HP StorageWorks Fibre Channel switches
Related documentation
For a list of corresponding documentation included with this product, see the Related documents
section of the HP StorageWorks Edge Switch release notes
.
For the latest information, documentation, and firmware releases, please visit the HP StorageWorks
web site:
http://h18006.www1.hp.com/storage/saninfrastructure.html
For information about Fibre Channel standards, visit the Fibre Channel Industry Association
web site:
http://www.fibrechannel.org
