Edge Switch 2/24 installation guide 25
10km Long Distance Optical Transceiver Kit
Part Number: 300835-B21
Provides 10 km long-wave optical
transceiver for the Edge Switch 2/24.
35 km Extended Reach Optical Transceiver Kit
Part Number: 300836-B21
Provides 35 km long-wave optical
transceiver for the Edge Switch 2/24.
Table 2 Edge Switch 2/24 optional kits (continued)
Supporting Kit Description
