Switch features24
Software diagnostics
The switch provides the following diagnostic software features that aid in fault isolation and repair
of problems:
• FRUs provide on-board diagnostic and monitoring circuits that continuously report FRU status to
the EWS, and HAFM applications. These applications provide system alerts and logs that
display failure and diagnostic information at the HAFM appliance or a remote workstation
communicating with the HAFM appliance.
• The HAFM Services application that runs as a Windows service and provides an additional user
interface to display operational status.
• The EWS interface that provides Ethernet access to isolate problems for a single switch.
• Unsolicited SNMP trap messages that indicate operational state changes or failures can be
transmitted to up to 12 authorized management workstations on an HAFM appliance, and up to
6 authorized management workstations on an edge switch or director.
• E-mail messages or call-home reports that provide automatic notification of significant system
events to designated support personnel or administrators.
Optional kits
Contact your Hewlett-Packard authorized service provider to purchase the following optional
Edge Switch 2/24 kits described in Table 2.
Table 2 Edge Switch 2/24 optional kits
Supporting Kit Description
8-flexport upgrade for Edge Switch 2/24
Part Number: 316096-B21
Used to upgrade the Edge Switch 2/24 from:
• 8 to 16 ports
• 16 to 24 ports.
Edge Switch 2/24 Product Manager License
Part Number: 317067-B21
Used when switch is managed through HAFM.
HP Open Trunking License
Part Number: 336002-B21
Provides a license to use the Open Trunking
feature.
HP SANtegrity Binding License
Part Number: 317073-B21
Provides a license to use the SANtegrity
Binding feature.
2Gb UPM Port Module Kit
Part Number: 316094-B21
Provides 4 additional short-wave ports for the
Edge Switch 2/24.
300m Optical Transceiver Kit
Part Number: 300834-B21
Provides short-wave optical transceiver for the
Edge Switch 2/24.
