HP StorageWorks Fabric OS 5.X Command Reference Guide (AA-RVHVB-TE, September 2005)

698 Fabric OS commands
Displays the policy parameters that determine overall switch status.
Synopsis
switchstatuspolicyshow
Availability
all users
Description
Use this command to view the current policy parameters set for the switch. These policy parameters
determine the number of failed or nonoperational units allowed for each contributor before triggering a
status change in the switch.
The command displays the current parameters in a three-column format, shown in Table 19. The first
column indicates the contributor, the second column indicates the minimum number that contributes to the
DOWN status, and the third column indicates the minimum number that contributes to the MARGINAL
status. The parameters can be set by the switchStatusPolicySet command. The existence of
policies, such as Fans, PowerSupplies, CP, WWN, and Blade, might differ from platform to platform. For
example, if the FaultyPorts DOWN parameter is set to 3, and three ports fail in the switch, then the status
of the switch changes to DOWN.
Operands
none
switchStatusPolicyShow
Table 19 Default contributor, values, and status
Contributor DOWN default MARGINAL default
PowerSupplies 2 1
Temperatures 2 1
Fans 2 1
WWN 0 1
CP 0 1
Blade 0 1
Flash 0 1
MarginalPorts 2 1
FaultyPorts 2 1
MissingSFPs 0 0
