HP StorageWorks Fabric OS 5.X Command Reference Guide (AA-RVHVB-TE, September 2005)

26 Fabric OS commands
are sent to the trap recipients. By default, this value is set to 0, implying that no such traps are sent.
Possible values are as follows:
See errModuleShow for related information.
The ACL check is as follows: there are six ACLs to restrict SNMP get/set/trap operations to hosts under a
host-subnet-area. Host-subnet-area is defined by comparing nonzero IP octets. For example, an ACL of
192.168.64.0 enables access by any hosts that start with the specified octets. The connecting host is
enabled to set each host-subnet-area to be read-write or read-only. The highest privilege matched out of
six entries is given to the access. The ACL check is turned off when all six entries contain 0.0.0.0.
NOTE: When secure mode is enabled, the access control list feature is incorporated into the WSNMP
and RSNMP security policies. Community strings can be changed on the primary FCS switch only and
will propagate changes across the fabric.
Operands
none
Examples
To reset the SNMP agent to default values:
0none
1critical
2error
3 warning
4 informational
5debug
switch:admin> agtcfgdefault
*****
This command will reset the agent's configuration back to factory
default
*****
Current SNMP Agent Configuration
Customizable MIB-II system variables:
sysDescr = Fibre Channel Switch.
sysLocation = End User Premise
sysContact = sweng
authTraps = 0 (OFF)
(continued on next page)
