RSCN Transmission mode
Table 7 lists the RSCN Transmission Mode fields and their settings.
Descriptions of the RSCN Transmission Mode field values are as follows:
Arbitrated Loop parameters
Table 8 lists the Arbitrated Loop Parameter fields.
Descriptions of the Arbitrated Loop Parameter fields are as follows:
Table 7 RSCN transmission modes
Field Type Default Range
End-device RSCN Transmission Mode number 1 0 to 2
Domain RSCN to End-device for switch IP address or name change number 0 0 to 1
End-device RSCN Transmission Mode Values:
0RSCN with single PID
1RSCN with multiple PIDs
2Fabric RSCN
Domain RSCN to End-device for switch
IP address or name change
Values :
0 Disabled. No domain RSCN is sent to the
end-device for the switch IP address or name
change.
1 Enabled. Domain RSCN is sent to the end-device
for the switch IP address or name change.
Table 8 Configure command arbitrated loop settings
Field Default Range
Send FAN frames? 1 0 or 1
Enable CLOSE on OPEN received? 4 0 to 4
Always send RSCN? 0 0 or 1
Send FAN frames? Specifies that fabric address notification (FAN) frames be sent to
public loop devices to notify them of their node ID and address.
When set to 1, frames are sent; when set to 0, frames are not
sent.
Enable CLOSE on OPEN
received?
If this is set, a CLS is returned immediately to an OPN if no
buffers are available. This is required for TachLite.
Always send RSCN? Following the completion of loop initialization, a remote state
change notification (RSCN) is issued when FL_Ports detect the
presence of new devices or the absence of preexisting devices.
When set, a RSCN is issued upon completion of loop
initialization, regardless of the presence or absence of new or
pre-existing devices.
