After you select OK, the Membership Partition Setup window shows the
partitions on the disk or LUN. Use the arrow keys to move among the
partitions. When a partition is highlighted, its size is displayed at the
bottom of the window. To select a partition to be used as a membership
partition, move to that partition and then press the spacebar. The
minimum size for a membership partition is 100 MB.
Membership Partition Setup
No partitions currently selected.
Select one or three disk partitions to use as membership
partitions.
Select a disk to see a list of partitions on that disk.
< OK > <Cancel>
UID:20:00:00:20:37:e4:f8:78::0 switch fcswitch6 port 0
UID:20:00:00:20:37:e4:f8:4a::0 switch fcswitch6 port 0
UID:20:00:00:20:37:e4:f8:75::0 switch fcswitch6 port 0
UID:20:00:00:20:37:e4:f8:77::0 switch fcswitch6 port 0
UID:20:00:00:20:37:e4:f7:f8::0 switch fcswitch6 port 0
Help Display help
Membership Partition Setup
No partitions currently selected.
Select one or three disk partitions to use as membership
partitions.
Select from the following partitions found on disk
UID:20:00:00:20:37:e4:f8:78::0
< OK > <Cancel>
[ ] Partition:1 Path:/dev/sdc1
[ ] Partition:2 Path:/dev/sdc2
[ ] Partition:3 Path:/dev/sdc3
[ ] Partition:4 Path:/dev/sdc4
