Appendix C: Configure the Matrix from the Command Line 68
Copyright © 1999-2007 PolyServe, Inc. All rights reserved.
SAN Configuration. You will next be asked whether you want to
configure the SAN switches in Matrix Server. This step is optional for
Web Management Based Fencing configurations; however, if the switches
are configured the Management Console can display the switch ports
used by the SAN.
If the SAN switches have not previously been configured in Matrix
Server, you will see the following window.
If Matrix Server detects an existing SAN switch configuration, the
following window will appear. You can retain, remove, or modify the
existing configuration.
SAN Configuration
SAN switch configuration is optional for the fence module
selected
Do you want to configure SAN switches?
< Yes > < No >
SAN Configuration
SAN switch configuration is optional for the fence module
selected
A SAN switch configuration already exists for this server.
How do you want to proceed with SAN configuration?
< OK > <Cancel>
Retain Retain existing SAN switch configuration
Reconfigure Reconfigure SAN switches
Remove Remove existing SAN switch configuration
