HP Storageworks Storage Mirroring Console user's guide (T2558-96330, April 2009)

6 - 8
Connection Statistics
Transmit Mode
 Active—Data is being transmitted from the source to the target.
 Paused—Data transmission has been paused.
 Scheduled—Data transmission is waiting on schedule criteria.
 Error—There is a transmission error.
 Unknown—Cannot determine the transmission status.
Target data state
 OK—The data on the target is in a good state.
 Mirroring—The target is in the middle of a mirror process. The data will
not be in a good state until the mirror is complete.
 Mirror Required—The data on the target is not in a good state because
a remirror is required. This may be caused by an incomplete or stopped
mirror or an operation may have been dropped on the target.
 Restore required—The data on the source and target do not match
because of a failover condition. Restore the data from the target back to
the source. If you want to discard the changes on the target, you can
remirror to resynchronize the source and target.
 Snapshot reverted—The data on the source and target do not match
because a snapshot has been applied on the target. Restore the data from
the target back to the source. If you want to discard the changes on the
target, you can remirror to resynchronize the source and target.
Target Route The IP address on the target to which the data is being transmitted.
Compression
 On / Level—Data is being compressed at the level specified.
 Off—Data is not being compressed.
Bandwidth Limit If bandwidth limiting has been set, this statistic identifies the limit. The
keyword Unlimited means there is no bandwidth limit set for the connection.
Connected Since The date and time when the current connection was made.
Statistic Description
Mirror Status
 Calculating—The size of the data to be mirrored is being calculated.
 In Progress—Data is being mirrored from the source to the target. If the
amount of data has been calculated, a percentage of the data that has
been sent will be displayed.
 Idle—Data is not being mirrored.
 Paused—Mirroring has been paused.
 Stopped—Mirroring has been stopped.
 Removing Orphans—Orphan files on the target are being removed.
 Verifying—Data is being verified between the source and target.
 Restoring—Data is being restored from the target to the source.
 Unknown—Cannot determine the mirroring status.
Mirror Percent
Complete
The percentage of the mirror that has been completed.
Mirror Remaining The total number of mirror bytes that are remaining to be sent from the
source to the target.
Mirror Skipped The total number of bytes that have been skipped when performing a
difference or checksum mirror. These bytes are skipped because the data is
not different on the source and target.
Statistic Description
