Viewing connection summary information
Each connection is displayed on the Monitor Connections page.
 Connection Information—The table at the top of the Monitor Connections page displays
summary information about connections. See the Connection Information table for a
description of what is displayed for each connection.
 Connection Filters—You can filter the connections shown using the toolbar buttons. See the
table Connection Filter Controls for a description of the filter controls.
Connection Information
Connection
Detail
Description
State The connection is in a healthy state.
The connection is in a warning state.
The connection is in an error state.
The connection is in an unknown state.
Connection The name of the connection.
Source Server The name of the source.
Target Server The name of the target.
Replication Set The name of the replication set.
Activity
 Connection pending—A connection has been configured but has not yet
been established.
 Connecting—Storage Mirroring Console is establishing communication
with the server.
 Authenticating—Storage Mirroring Console is verifying credentials with
the server.
 Polling—Storage Mirroring Console is gathering data from the server.
 Idle—Storage Mirroring Console is not presently generating any activity
on the server.
 Cannot connect to server—Storage Mirroring Console cannot
communicate with Storage Mirroring on the server.
 Name resolution failed—Storage Mirroring Console cannot find a server
with this name.
Mirror Status
 Calculating—The size of the data to be mirrored is being calculated.
 In Progress—Data is being mirrored from the source to the target. If the
amount of data has been calculated, a percentage of the data that has
been sent will be displayed.
 Idle—Data is not being mirrored.
 Paused—Mirroring has been paused.
 Stopped—Mirroring has been stopped.
 Removing Orphans—Orphan files on the target are being removed or
deleted depending on the configuration.
 Verifying—Data is being verified between the source and target.
 Restoring—Data is being restored from the target to the source.
 Unknown—Cannot determine the mirroring status.
