Database tables and fields
H
QUEUE_DEPTH The number of I/O operations that can be run in
parallel on a device.
The default value is 0.
int
INTERRUPT_CONTROL_COA
LESCE
Indicates whether interrupt control is on or off.
The default value is 0.
smallint
INTERRUPT_CONTROL_LAT
ENCY
Sets the interrupt control latency value..
The default value is 0.
int
INTERRUPT_CONTROL_DEL
AY
Sets the interrupt control delay value..
The default value is 0.
int
BEACON_STATE Indicates whether beaconing is on or off..
The default value is 0.
smallint
LINK_BEACON_STATE Indicates whether link beaconing is on or off..
The default value is 0.
smallint
MPIO_MODE_STATE Indicates whether multipathing mode is on or off..
The default value is 0.
smallint
PATH_TIME_OUT
The value between 0 to 60 that specifies the time out
session. Note you can only enable or edit the path
time out when MPIO is disabled.
The default value is 0.
int
LOGGING_LEVEL
The port logging level. Values include Log Critical, Log
Error, Log Warning, and Log Info. The default value is
0.
smallint
TARGET_RATE_LIMIT Target rate limit of the port. Possible values are 0
-disabled, 1 - enabled. The default value is 0.
smallint
DEFAULT_RATE_LIMIT Default target rate limit of the port speed (1 Gbps).
The default value is 0.
int
VF_MODE True if the port is in VF (Virtual Fabric) mode. smallint
RECIEVE_BUFFER_CREDIT Receiving buffer-to-buffer credits (BB_credits) for the
port.
varchar 64
TRANSMIT_BUFFER_CREDI
T
Transmitting buffer-to-buffer credits (BB_credits) for
the port.
varchar 64
FCSP_AUTH_STATE Indicates whether FC-SP authentication is on or off.
The default value is 0.
smallint
FCSP_STATUS The status of FC-SP authentication.
The default value is 'Disabled'.
varchar 32
FCSP_ALGORITHM The configured authentication algorithm.
The default value is 'MD5'.
varchar 64
FCSP_GROUP The DH Group (DH Null, group 0 is the only option).
The default value is 0.
smallint
FCSP_ERROR_STATUS The health status of the Fibre Channel Security
Protocol parameters
varchar 256
TABLE 215 HBA_PORT_DETAIL (Continued)
Field Definition Format Size
