Database tables and fields
H
VM_DV_PORT_ID Foreign key to the vm_dv_port table. DV Port
with which this vmknic is associated
int
MTU The MTU of the port int
VM_HOST_ID FOREIGN KEY to the vm_host table int
MOR_ID The managed object reference number
assigned by the hypervisor
int
PORT_GROUP_KEY The key for the port group varchar 256
BINARY_MAC MAC address in binary format. bytea
BINARY_IP IP address in binary format. bytea
TABLE 432 VM_NETWORK_SETTINGS
Field Definition Format Size
ID Unique generated database identifier. serial
VLAN_TYPE One of:
Private VLAN
Trunk VLAN
Access VLAN
smallint
VLAN_IDS Single or range of VLANs configured on the port varchar 256
BLOCKED Whether this port is blocked, i.e. packet
forwarding is stopped
int
VM_STD_VSWITCH_POR
T_GROUP_ID
ID of standard vSwitch port group int
VM_STANDARD_VIRTUA
L_SWITCH_ID
ID of standard vSwitch int
VM_DV_SWITCH_ID ID of distributed vSwitch int
VM_DV_PORT_GROUP_I
D
ID of distributed vSwitch port group int
VM_DV_PORT_ID ID of distributed vSwitch port int
TABLE 433 VM_NIC_TEAMING_POLICY
Field Definition Format Size
ID Unique generated database identifier. serial
NOTIFY_SWITCHES Flag to specify whether or not to notify the physical switch if a
link fails. If this property is true, ESX Server will respond to
the failure by sending a RARP packet from a different
physical adapter, causing the switch to update its cache.
smallint
POLICY Network adapter teaming policy includes failover and load
balancing, It can be one of the following:
• loadbalance_ip: route based on ip hash.
• loadbalance_srcmac: route based on source MAC hash.
• loadbalance_srcid: route based on the source of the
port ID.
• failover_explicit: use explicit failover order.
smallint
TABLE 431 VM_HOST_VIRTUAL_NIC (Continued)
Field Definition Format Size
