Crypto LUN configuration
3
LUN serial number:
Key ID state: Key ID not Applicable
b. Add the LUN to the tape CryptoTarget container. The following example enables the LUN for
encryption. There is a maximum of eight tape LUNs per Initiator in a container.
FabricAdmin:switch> cryptocfg --add -LUN my_tape_tgt 0x0 \
10:00:00:00:c9:2b:c9:3a 20:00:00:00:c9:2b:c9:3a -encrypt
Operation Succeeded
NOTE
When changing the tape LUN policy from encrypt to cleartext or from cleartext to encrypt,
or the encryption format from Brocade native to DF-compatible while data is being written
to or read from a tape backup device, the policy change is not enforced until the current
process completes and the tape is unmounted, rewound, or overwritten. Refer to the
section “Impact of tape LUN configuration changes” on page 179 for more information.
c. Commit the configuration.
FabricAdmin:switch> cryptocfg --commit
Operation Succeeded
d. Display the LUN configuration.
FabricAdmin:switch> cryptocfg --show -LUN my_tape_tgt 0x0 \
10:00:00:00:c9:2b:c9:3a -cfg
EE node: 10:00:00:05:1e:41:9a:7e
EE slot: 0
Target: 20:0c:00:06:2b:0f:72:6d 20:00:00:06:2b:0f:72:6d
VT: 20:00:00:05:1e:41:4e:1d 20:01:00:05:1e:41:4e:1d
Number of host(s): 1
Configuration status: committed
Host: 21:00:00:e0:8b:89:9c:d5 20:00:00:e0:8b:89:9c:d5
VI: 10:00:00:00:c9:2b:c9:3a 20:03:00:05:1e:41:4e:31
LUN number: 0x0
LUN type: tape
LUN status: 0
Encryption mode: encrypt
Encryption format: DF_compatible
Tape type: tape
Key life: 90 (day)
Volume/Pool label:
Operation succeeded.
