Managing Serviceguard 11th Edition, Version A.11.16, Second Printing June 2004

Configuring Packages and Their Services
Writing the Package Control Script
Chapter 6 259
How Control Scripts Manage VxVM Disk Groups
VxVM disk groups outside CVM are outside the control of the
Serviceguard cluster. The package control script uses standard VxVM
commands to import and deport these disk groups. (For details on
importing and deporting disk groups, refer to the discussion of the
import and deport options in the vxdg man page.)
The control script imports disk groups using the vxdg command with the
-tfC options. The -t option specifies that the disk is imported with the
noautoimport flag, which means that the disk will not be automatically
re-imported at boot time. Since disk groups included in the package
control script are only imported by Serviceguard packages, they should
not be auto-imported.
The -f option allows the disk group to be imported even if one or more
disks (a mirror, for example) is not currently available. The -C option
clears any existing host ID that might be written on the disk from a prior
activation by another node in the cluster. If the disk had been in use on
another node which has gone down with a TOC, then its host ID may still
be written on the disk, and this needs to be cleared so the new node’s ID
can be written to the disk. Note that the disk groups are not imported
clearing the host ID if the host ID is set and matches a node that is not in
a failed state. This is to prevent accidental importation of a disk group on
multiple nodes which could result in data corruption.
WARNING Although Serviceguard uses the -C option within the package
control script framework, this option should not normally be
used from the command line. The “Troubleshooting” section
shows some situations where you might need to use -C from the
command line.
The following example shows the command with the same options that
are used by the control script:
# vxdg -tfC import dg_01
This command takes over ownership of all the disks in disk group dg_01,
even though the disk currently has a different host ID written on it. The
command writes the current node’s host ID on all disks in disk group
dg_01 and sets the noautoimport flag for the disks. This flag prevents a
disk group from being automatically re-imported by a node following a
reboot. If a node in the cluster fails, the host ID is still written on each
