happens if the server is an adoptive node for a file system, and the file system is available
on the server only after failover of the primary node.
“-o fsid=<number>” must be used to force the file system ID portion of the file handle to be
<number> when clusters are composed of mixed architectures such as HP Integrity servers
and HP 9000 Series 800 computers over CFS. A value between 1 and 32767 may be used,
but must be unique among the shared file systems. See share_nfs(1m) for detailed information.
2. If you wish to monitor NFS services (by running the NFS monitor script), set the
NFS_SERVICE_NAME and NFS_SERVICE_CMD variables; see the following example:
NFS_SERVICE_NAME[0]=nfs1.monitor
NFS_SERVICE_CMD[0]=/etc/cmcluster/nfs/nfs.mon
If you enable the File Lock Migration feature, ensure that the monitor script name is unique
for each package (for example, nfs1.mon). If the File Lock Migration feature is disabled,
the monitor script name does not have to be unique to each package (for example, nfs.mon).
Multiple instances of the monitor script can run on the same node without any problem. If
a package fails over, only the instance associated with that package is killed.
3. You do not have to run the NFS monitor script. If your NFS package configuration file
specifies AUTO_RUN YES and LOCAL_LAN_FAILOVER_ALLOWED YES (the defaults), the
package switches to the next adoptive node or to a standby network interface in the event
of a node or network failure. The NFS monitor script causes the package failover if any of
the monitored NFS services fails.
If you do not want to run the NFS monitor script, comment out the NFS_SERVICE_NAME
and NFS_SERVICE_CMD variables:
# NFS_SERVICE_NAME[0]=nfs.monitor
# NFS_SERVICE_CMD[0]=/etc/cmcluster/nfs/nfs.mon
By default, the NFS_SERVICE_NAME and NFS_SERVICE_CMD variables are commented
out, and the NFS monitor script is not run.
NOTE: The Serviceguard A.11.13 configuration file includes the following changes:
• AUTO_RUN replaces obsolete PKG_SWITCHING_ENABLED.
• LOCAL_LAN_FAILOVER_ALLOWED replaces obsolete NET_SWITCHING_ENABLED.
4. To enable File Lock Migration (available on 11i v1 and 11i v2), set the
NFS_FILE_LOCK_MIGRATION variable to 1:
NFS_FILE_LOCK_MIGRATION=1
By default, this variable is set to 0 (disabled). The NFS_FLM_SCRIPT variable is the name
of the script that manages synchronization of the file lock status entries for the primary and
adoptive nodes associated with this HA/NFS package. By default, this is set to nfs.flm.
You must assign a unique name to this script in every HA/NFS package in the cluster (for
example, nfs1.flm, nfs2.flm, and so on):
NFS_FLM_SCRIPT="${0%/*}/nfs1.flm"
If you wish to monitor the File Lock Migration script, then you must also set the
NFS_FILE_LOCK_MIGRATION and NFS_FLM_SCRIPT variables in the NFS monitor script.
If you enable File Lock Migration, then you can configure the File Lock Migration script (see
“Editing the File Lock Migration Script (nfs.flm)” (page 33)).
