Serviceguard Configuration for Oracle RAC
Creating a Storage Infrastructure with CVM
Chapter 258
Create these files if you wish to build the demo database. The three
logical volumes at the bottom of the table are included as additional data
files, which you can create as needed, supplying the appropriate sizes. If
your naming conventions require, you can include the Oracle SID and/or
the database name to distinguish files for different instances and
different databases. If you are using the ORACLE_BASE directory
structure, create symbolic links to the ORACLE_BASE files from the
appropriate directory.
Example, Oracle8:
temp.dbf 108 /dev/vx/rdsk/ops_dg/temp.dbf 100
users.dbf 128 /dev/vx/rdsk/ops_dg/users.dbf 120
tools.dbf 24 /dev/vx/rdsk/ops_dg/tools.dbf 15
opsdata1.dbf 208 /dev/vx/rdsk/ops_dg/opsdata1.dbf 200
opsdata2.dbf 208 /dev/vx/rdsk/ops_dg/opsdata2.dbf 200
opsdata3.dbf 208 /dev/vx/rdsk/ops_dg/opsdata3.dbf 200
ops2log1 28 /dev/vx/rdsk/ops_dg/ops2log1.log 20
ops2log2 28 /dev/vx/rdsk/ops_dg/ops2log2.log 20
ops2log3 28 /dev/vx/rdsk/ops_dg/ops2log3.log 20
ops3log1 28 /dev/vx/rdsk/ops_dg/ops2log1.log 20
ops3log2 28 /dev/vx/rdsk/ops_dg/ops2log2.log 20
ops3log3 28 /dev/vx/rdsk/ops_dg/ops2log3.log 20
opsdata1 208 /dev/vx/rdsk/ops_dg/opsdata1.dbf 200
opsdata2 208 /dev/vx/rdsk/ops_dg/opsdata2.dbf 200
opsdata3 208 /dev/vx/rdsk/ops_dg/opsdata3.dbf 200
Table 2-2 Required Oracle File Names for Demo Database (Continued)
Volume Name
Size
(MB) Raw Device File Name
Oracle
File Size
(MB)
