Serviceguard Configuration for Oracle RAC
Creating a Storage Infrastructure with CVM
Chapter 2 57
Mirror Detachment Policies with CVM
The required CVM disk mirror detachment policy is ‘global’, which
means that as soon as one node cannot see a specific mirror copy (plex),
all nodes cannot see it as well. The alternate policy is ‘local’, which
means that if one node cannot see a specific mirror copy, then CVM will
deactivate access to the volume for that node only.
This policy can be re-set on a disk group basis by using the vxedit
command, as follows:
# vxedit set diskdetpolicy=global <DiskGroupName>
NOTE The specific commands for creating mirrored and multi-path storage
using CVM are described in the HP-UX documentation for the VERITAS
Volume Manager.
Oracle Demo Database Files
The following set of volumes is required for the Oracle demo database
which you can create during the installation process.
Table 2-2 Required Oracle File Names for Demo Database
Volume Name
Size
(MB) Raw Device File Name
Oracle
File Size
(MB)
opsctl1.ctl 108 /dev/vx/rdsk/ops_dg/opsctl1.ctl 100
opsctl2.ctl 108 /dev/vx/rdsk/ops_dg/opsctl2.ctl 100
opsctl3.ctl 108 /dev/vx/rdsk/ops_dg/opsctl3.ctl 100
system.dbf 408 /dev/vx/rdsk/ops_dg/system.dbf 400
ops1log1.log 28 /dev/vx/rdsk/ops_dg/ops1log1.log 20
ops1log2.log 28 /dev/vx/rdsk/ops_dg/ops1log2.log 20
ops1log3.log 28 /dev/vx/rdsk/ops_dg/ops1log3.log 20
system.dbf 408 /dev/vx/rdsk/ops_dg/system1.dbf 400
