Serviceguard Configuration for Oracle RAC
Installing Oracle Real Application Clusters
Chapter 2 49
Installing Oracle Real Application Clusters
NOTE Some versions of Oracle RAC requires installation of additional software.
Refer to your version of Oracle for specific requirements.
Before installing the Oracle Real Application Cluster software, make
sure the cluster is running. Log in as the oracle user on one node and
then use the Oracle installer to install Oracle software and to build the
correct Oracle runtime executables. The Oracle installer also copies
the executables to the other nodes in the cluster. Select the following
installation option to install RAC software and to create the demo
database:
COMPLETE SOFTWARE/DATABASE FRESH INSTALL
Refer to your Oracle installation documentation for Oracle installation
details. As part of this installation, the Oracle installer builds the Oracle
demo database on the primary node, using the character (raw) device file
names for the logical volumes created earlier. For the demo database,
create fourteen logical volumes as shown in the table “Required Oracle
File Names for Demo Database” earlier in this chapter. As the installer
prompts for database file names, enter the pathnames of the raw logical
volumes instead of using the defaults. If you do not wish to install the
demo database, select:
SOFTWARE INSTALL ONLY
In this case, create an appropriate number of raw logical volumes to
build your development or production system. Be sure to create enough
log files for all instances.
