Serviceguard Configuration for Oracle RAC
Creating a Storage Infrastructure with LVM
Chapter 2 45
Oracle Demo Database Files
The following set of files is required for the Oracle demo database which
you can create during the installation process.
Table 2-1 Required Oracle File Names for Demo Database
Logical Volume Name
LV
Size
(MB) Raw Logical Volume Path Name
Oracle
File
Size
(MB)*
opsctl1.ctl 108 /dev/vg_ops/ropsctl1.ctl 100
opsctl2.ctl 108 /dev/vg_ops/ropsctl2.ctl 100
opsctl3.ctl 108 /dev/vg_ops/ropsctl3.ctl 100
system.dbf 408 /dev/vg_ops/rsystem.dbf 400
ops1log1.log 28 /dev/vg_ops/rops1log1.log 20
ops1log2.log 28 /dev/vg_ops/rops1log2.log 20
ops1log3.log 28 /dev/vg_ops/rops1log3.log 20
system.dbf 408 /dev/vg_ops/rsystem1.dbf 400
temp.dbf 108 /dev/vg_ops/rtemp.dbf 100
users.dbf 128 /dev/vg_ops/rusers.dbf 120
tools.dbf 24 /dev/vg_ops/rtools.dbf 15
opsdata1.dbf 208 /dev/vg_ops/ropsdata1.dbf 200
opsdata2.dbf 208 /dev/vg_ops/ropsdata2.dbf 200
opsdata3.dbf 208 /dev/vg_ops/ropsdata3.dbf 200
ops2log1 28 /dev/vg_ops/rops2log1.log 20
ops2log2 28 /dev/vg_ops/rops2log2.log 20
ops2log3 28 /dev/vg_ops/rops2log3.log 20
ops3log1 28 /dev/vg_ops/rops2log1.log 20
ops3log2 28 /dev/vg_ops/rops2log2.log 20
