Serviceguard Configuration for Oracle RAC
Creating a Storage Infrastructure with LVM
Chapter 2 41
PVG-strict, that is, it occurs between different physical volume groups;
the -n redo1.log option lets you specify the name of the logical volume;
and the -L 4 option allocates 4 megabytes.
NOTE It is important to use the -M n and -c y options for both redo logs and
control files. These options allow the redo log files to be resynchronized
by SLVM following a system crash before Oracle recovery proceeds. If
these options are not set correctly, you may not be able to continue with
database recovery.
If the command is successful, the system will display messages like the
following:
Logical volume “/dev/vg_ops/redo1.log” has been successfully
created
with character device “/dev/vg_ops/rredo1.log”
Logical volume “/dev/vg_ops/redo1.log” has been successfully
extended
Note that the character device file name (also called the raw logical
volume name) is used by the Oracle DBA in building the RAC database.
Creating Mirrored Logical Volumes for RAC Data Files
Following a system crash, the mirrored logical volumes need to be
resynchronized, which is known as “resilvering”.
If Oracle does not perform “resilvering” of RAC data files that are
mirrored logical volumes, choose a mirror consistency policy of
“NOMWC”. This is done by disabling mirror write caching and enabling
mirror consistency recovery. With “NOMWC”, SLVM performs the
resynchronization.
Create logical volumes for use as Oracle data files by using the same
options as in the following example:
# lvcreate -m 1 -M n -c y -s g -n system.dbf -L 28 /dev/vg_ops
The -m 1 option specifies single mirroring; the -M n option ensures that
mirror write cache recovery is set off; the -c y means that mirror
consistency recovery is enabled; the -s g means that mirroring is
PVG-strict, that is, it occurs between different physical volume groups;
the -n system.dbf option lets you specify the name of the logical
volume; and the -L 28 option allocates 28 megabytes.
