6 Using an Apache Toolkit in a HP Serviceguard Cluster
This chapter describes the HP Apache toolkit that runs in the HP Serviceguard environment. You
can install, configure, and run the Apache web server application in a Serviceguard clustered
environment. To use this toolkit you must be familiar with Serviceguard and the Apache web server,
including installation, configuration, and execution.
NOTE: This toolkit supports:
• HP Serviceguard versions
◦ A.11.19
◦ A.11.20
• Apache version that is available with HP Web Server Suite(WSS) 2.X and 3.X and,
• HP-UX 11i v2 and HP-UX 11i v3
• The latest versions of these products may be certified with B.06.00. For the latest information,
see the compatibility matrix available at http://www.hp.com/go/hpux-serviceguard-docs
—>HP Serviceguard
This version B.06.00 of the toolkit supports both legacy and modular style packages.
It supports all filesystems, storage, and volume managers that Serviceguard supports.
This toolkit includes support for the following:
• HP Serviceguard A.11.19 with VERITAS Cluster File System (CFS) 5.0 on HP-UX 11i v2, and
HP-UX 11i v3.
• HP Serviceguard A.11.19 with CFS 5.0.1 on HP-UX 11i v3.
• HP Serviceguard A.11.20 with CFS 5.1 SP1 on HP-UX 11i v3
To use CFS, install the appropriate version of HP Serviceguard Storage Management Suite. For
more information, see the Serviceguard Release Notes at: http://www.hp.com/go/
hpux-serviceguard-docs ->Serviceguard and the Storage Management Suite Release Notes .
This toolkit consists of a set of shell scripts for configuring, starting, monitoring, and stopping the
Apache web server application. The toolkit works with the Serviceguard package control script,
managed by Serviceguard for legacy packages and Serviceguard master control script for modular
packages. Each Apache instance is configured in its own Serviceguard package. You must be
familiar with swinstall to properly install both Serviceguard and the Enterprise Cluster Master Toolkit
(ECMT) which includes the scripts for Apache. Table 22 (page 98) lists the files needed during
installation, that are available in/opt/cmcluster/toolkit/apache.
Table 22 Files in Apache Toolkit
DescriptionFile Name
The content of this README has been moved to this user guide.README
User defined variables for customizing this toolkit for your environment.hahttp.conf
The main shell script.hahttp.sh
Script that monitors the health of the Server application.hahttp.mon
Interface between the package control script and the Apache Toolkit main shell
script.
toolkit.sh
This generates the alert mail based on package failureSGAlert.sh
