HP Serviceguard Enterprise Cluster Master Toolkit User Guide (5900-2145, April 2013)
Table Of Contents
- HP Serviceguard Enterprise Cluster Master Toolkit User Guide
- Contents
- 1 Introduction
- 2 Using the Oracle Toolkit in an HP Serviceguard Cluster
- Overview
- Supported Versions
- Support for Oracle Database Without ASM
- Supporting Oracle ASM Instance and Oracle Database with ASM
- What is Automatic Storage Management (ASM)?
- Why ASM over LVM?
- Configuring LVM Volume Groups for ASM Disk Groups
- Sample command sequence for configuring LVM Volume Groups
- Serviceguard support for ASM on HP-UX 11i v3 onwards
- Framework for ASM support with Serviceguard
- Installing, Configuring, and Troubleshooting
- Setting up DB instance and ASM instance
- Setting up the Toolkit
- ASM Package Configuration Example
- Modifying a Legacy Database Package Using an Older Version of Oracle ECMT Scripts to use the Scripts Provided for ASM Support
- Adding the Package to the Cluster
- Node-specific Configuration
- Error Handling
- Network Configuration
- Database Maintenance
- Configuring and packaging Oracle single-instance database to co-exist with SGeRAC packages
- Configuring Oracle single-instance database that uses ASM in a Coexistence Environment
- Attributes newly added to ECMT Oracle toolkit
- Configuring a modular failover package for an Oracle database using ASM in a coexistence environment
- Configuring a legacy failover package for an Oracle database using ASM in a Coexistence Environment
- ECMT Oracle Toolkit Maintenance Mode
- Supporting EBS database Tier
- Oracle ASM Support for EBS DB Tier
- 3 Using the Sybase ASE Toolkit in a Serviceguard Cluster on HP-UX
- Overview
- Sybase Information
- Setting up the Application
- Setting up the Toolkit
- Sybase Package Configuration Example
- Creating the Serviceguard package using Modular method
- Adding the Package to the Cluster
- Node-specific Configuration
- Error-Handling
- Network configuration
- Database Maintenance
- Cluster Verification for Sybase ASE Toolkit
- 4 Using the DB2 Database Toolkit in a Serviceguard Cluster in HP-UX
- 5 Using MySQL Toolkit in a HP Serviceguard Cluster
- MySQL Package Configuration Overview
- Setting Up the Database Server Application
- Setting up MySQL with the Toolkit
- Package Configuration File and Control Script
- Creating Serviceguard Package Using Modular Method
- Applying the Configuration and Running the Package
- Database Maintenance
- Guidelines to Start Using MySQL Toolkit
- 6 Using an Apache Toolkit in a HP Serviceguard Cluster
- 7 Using Tomcat Toolkit in a HP Serviceguard Cluster
- Tomcat Package Configuration Overview
- Multiple Tomcat Instances Configuration
- Configuring the Tomcat Server with Serviceguard
- Setting up the Package
- Creating Serviceguard Package Using Modular Method
- Setting up the Toolkit
- Error Handling
- Tomcat Server Maintenance
- Configuring Apache Web Server with Tomcat in a Single Package
- 8 Using SAMBA Toolkit in a Serviceguard Cluster
- 9 Using HP Serviceguard Toolkit for EnterpriseDB PPAS in an HP Serviceguard Cluster
- 10 Support and Other resources
- 11 Acronyms and Abbreviations
- Index
NOTE: HP supports the placement of the EDB binaries on the shared storage but does not
recommend this configuration, if multiple instances are configured. This is because, if multiple EDB
instances using the shared EDB binaries are configured, where one of the EDB instance fails and
needs to failover to adoptive node, the file system that holds the EDB binary on the primary node
must be unmounted, and then remounted on the adoptive node. This impacts other EDB instances
hosted on the primary node.
HP recommends that you should not place the EDB binaries on the shared location, when multiple
instances of EDB are configured.
Installing and Uninstalling HP Serviceguard Toolkit for EnterpriseDB PPAS
The HP Serviceguard Toolkit for EnterpriseDB PPAS is a part of ECMT, hence, this toolkit is
automatically installed when you install ECMT B.07.00.01.
For more information on installing and uninstalling ECMT, see “ Installing and Uninstalling Enterprise
Cluster Master Toolkit” (page 8)
Files and directories created for HP Serviceguard Toolkit for EnterpriseDB PPAS after
installation
The following table indicates the scripts installed and their location as part of the HP Serviceguard
Toolkit for EnterpriseDB PPAS installation.
Table 36 Files created after HP Serviceguard Toolkit for EnterpriseDB PPAS is installed
Available in DirectoryDescriptionFile Name
/opt/cmcluster/toolkit/edbThis script starts and stops the
EnterpriseDB instance.
haedb.sh
This script monitors the EnterpriseDB
instance.
haedb.mon
This script generates alert mails when
a package failure occurs.
SGAlert.sh
Table 37 Files for the ADF module
Available in DirectoryDescriptionFile Name
/etc/cmcluster/modules/ecmt/
edb
This file has all the definitions of
required parameters for HP
Serviceguard Toolkit for EnterpriseDB
edb.1
PPAS. The ADF file is used to generate
the modular package ASCII template
file.
Table 38 Module scripts used in modular method of packaging
Available in DirectoryDescriptionFile Name
/etc/cmcluster/scripts/ecmt/
edb
This script is called by the master
control script and acts as an interface
between the master control script and
the toolkit scripts.
tkit_module.sh
Using HP Serviceguard Toolkit for EnterpriseDB PPAS
After installing the HP Serviceguard Toolkit for EnterpriseDB PPAS, you can use this toolkit to:
1. Create the Serviceguard package using the modular method, to manage the EnterpriseDB
PPAS server
2. Manage databases or packages
138 Using HP Serviceguard Toolkit for EnterpriseDB PPAS in an HP Serviceguard Cluster
