Enterprise Cluster Master Toolkit Version B.06.00 Release Notes, September 2010 (T1909-90071)

• A main script that controls the process flow of the toolkit.
• A monitor script that ensures the application is running while the package is up.
NOTE:
• In addition to these files, the Oracle toolkit also contains some helper scripts that are internally
used by the main script or the monitor script.
• The interface script toolkit.sh, configuration file, main script and monitor script are not
present in the Sybase toolkit.
The Enterprise Cluster Master Toolkit structure also contains the following files that are used
only for modular packages:
• An application module that contains an attribute for every parameter in the configuration
file. It also has an additional attribute TKIT_DIR, which is analogous to the package directory
in legacy packages.
• A module script that acts as an interface between the Serviceguard Master Control Script and
the Interface Script. (When using Sybase toolkit, the module script is called by the
Serviceguard Master Control Script to start, stop and monitor the application.)
• A toolkit configuration file generator script that is called by the module script by cmapplyconf
to generate the configuration file in TKIT_DIR. (The Sybase toolkit does not have a
configuration file, therefore this script is not present).
What’s in this Version
The Enterprise Cluster Master Toolkit version B.06.00 includes the following:
• Support for HP Serviceguard A.11.19 and A.11.20
• Support for Oracle 11g R1
• Support for Oracle 11g R2 on HP Integrity with HP-UX 11i v3
• Support for IBM DB2 v9.1, 9.5 (single partition) and 9.7 (single partition) on HP Integrity
servers
• Support for HP Apache, HP CIFS, and Oracle 10g R2, 11g R1 with CVM/CFS 5.0.1
• Support for Apache version 2.2
• Support for HP Virtual Machines 4.2
• Support for the alert notification feature
• Support for detecting the Oracle database hang
• Support for IPv6 protocol
• Support for installation using Dynamic Root Disk utilities on 11i v3
• Support for multiple listeners in the Oracle toolkit
• Fix to the Oracle toolkit to support Oracle 11g R1 11.1.0.7 ASM
• Fix to ensure that the Listener is stopped appropriately before attempting to restart it
• Fix to ensure that the correct Listener process ID is selected to kill the listener during Oracle
package halt.
Compatibility Information and Installation Requirements
Compatibility
The Enterprise Cluster Master Toolkit requires the installation of supported versions of the
HP-UX operating system together with HP Serviceguard.
The following are compatible versions with the Enterprise Cluster Master Toolkit version B.06.00:
• HP-UX 11i v2 and 11i v3
• HP Serviceguard versions A.11.19 and A.11.20
6 Enterprise Cluster Master Toolkit Version B.06.00 Release Notes
