Table 27 History Window
DescriptionItem
Allows you to return to the previous page of the list. This button is selectable only when
the number of operation histories in the storage system exceeds 16,384, which is the
Previous button
maximum number of histories that can be displayed on one page. The button is grayed
out if the total number of operation histories in the storage system is less than 16,384.
Allows you to turn to the next page of the list. This button is selectable only when the
number of operation histories in the storage system exceeds 16,384 volumes, which is
Next button
the maximum number of histories that can be displayed on one page. The button is
grayed out if the total number of operation histories in the storage system is less than
16,384.
Displays the date and time (YYYY/MM/DD hour/min/sec) when an XP Business Copy
pair or volume operation has been performed.
Date
The XP Business Copy pair status of the volume pair. For details about the XP Snapshot
status, see the HP XP24000/XP20000 Snapshot User Guide.
Status
Displays the LDKC:CU:LDEV of the P-VOLs used for pair operation in the past.P-VOL
Displays the LDKC:CU:LDEV of the S-VOLs used for pair operation in the past.S-VOL
Displays the XP Business Copy reference codes.Code
Displays the messages to inform the conditions of the past XP Business Copy pair
operations.
Message
XP Business Copy status and history reference codes and messages are listed in Table 28 (page
58).
Table 28 XP Business Copy Status and History Reference Codes and Messages
DescriptionMessageCode
The XP Business Copy initial copy operation started.PAIR START4710
The XP Business Copy initial copy operation ended, and the
pair status changed to PAIR.
PAIR END4720
The XP Business Copy pairsplit operation started.PSUS START4730
The XP Business Copy pairsplit operation ended, and the
pair status changed to PSUS.
PSUS END4740
The XP Business Copy pairresync operation started.COPY(RS) START4750
COPY(RS-R) START
The XP Business Copy pairresync operation ended, and the
pair status changed to PAIR.
COPY(RS) END
COPY(RS-R) END
4760
The XP Business Copy pairsplit-S operation was performed,
and the pair status changed to SMPL.
SMPL4780
The XP Business Copy pairsplit-E operation was performed,
and the pair status changed to PSUE.
PSUE4790
A copy ended abnormally (reason other than above).COPY ABNORMAL END47D0
Initialization started.INITIALIZE START47E9
Initialization ended normally.INITIALIZE END47EA
Initialization ended abnormally.INITIALIZE ENDED ABNORMAL47EB
