Figure 26 Preview List Displaying Settings (Operations)
Table 25 Preview List Settings
DescriptionItem
Information about P-VOL displays in AAA-BB-CCC(XX:YY:ZZ) format.P-VOL
• AAA: Port ID (cluster and channel number)
• BB: Group number of host group
• CCC: LU number
• XX:YY:ZZ: LDKC number:CU number:LDEV number
The MU number of the XP Business Copy pair created with the P-VOL. For details about
what displays in this item if you select XP Snapshot pairs, see the HP XP24000/XP20000
Snapshot User Guide.
MU
The information about S-VOL displays in AAA-BB-CCC(XX:YY:ZZ) format.S-VOL
• AAA: Port ID (cluster and channel number)
• BB: Group number of host group
• CCC: LU number
• XX:YY:ZZ: LDKC number:CU number:LDEV number
The copying pace for all pairs being created. For details about what displays in this item
if you select XP Snapshot pairs, see the HP XP24000/XP20000 Snapshot User Guide.
Copy Pace
The cache logical partition of the P-VOL displays.CLPR (P)
The cache logical partition of the S-VOL displays.CLPR (S)
If the specified operation in the Preview List is performed by clicking the Apply button in
the Pair Operation window, and the operation fails, the reason code displays.
Error Code
The information displays in the information field below the Preview List.
Preview: X(Y)/Z, where:
X = the number of settings remaining in the Preview List that are still not applied to the storage
system
Y = the type of pair operation
Z = command option
You can change the Preview List by right-click the setting in the Preview List and displaying the
menus. Table 26 (page 57) lists the available menu commands in the Preview List.
