HP StorageWorks XP24000/XP20000 SNMP Agent Reference Guide (AE131-96088, May 2011)

Table 18 SNMP Failure Trap Reference Codes (continued)
Alert LevelDescriptionTrap Reference Code
SIM13SIM23SIM22
SERIOUSVolume used as P-VOL has been
suspended (S-VOL suspension detected)
xx4xDC
SERIOUSVolume used as P-VOL has been
suspended (S-VOL pair deletion detected)
xx5xDC
SERIOUSVolume used as S-VOL has been
suspended (Unable to restore path)
xx6xDC
SERIOUSVolume used as S-VOL has been
suspended (RCU failure detected)
xx7xDC
SERIOUSVolume used as a P-VOL of Delta resync
has been suspended
x: The CU number
yy: The LDEV number
yy9xDC
SERIOUSVolume in the main storage system has
been suspended because failure suspend
occurs in the remote storage system.
yyAxDC
MODERATECopying ended abnormallyxxDx47
MODERATEHP StorageWorks XP for FlashCopy
Mirroring Software V2 ended abnormally
because of loss of data from the shared
memory
xxE547
MODERATECompatible FlashCopy ended abnormally
because of loss of data from the shared
memory
xxE647
MODERATEPair has been suspended forcibly
because of loss of data from the shared
memory.
00E747
MODERATEThe HP StorageWorks XP Snapshot
option ended abnormally due to
volatilization of the shared memory.
00EC47
MODERATEFailure with paired
volumes
XP Auto LUN ended abnormallyxxFx47
MODERATECopy failureBackground copying for canceling
relationship ended abnormally
xx0x4B
MODERATEFailure with paired
volumes
Compatible FlashCopy V2 ended
abnormally
x: The CU number
yy: The LDEV number
yy2x4B
MODERATEThe XP Snapshot option ended
abnormally.
yy3x4B
MODERATEXP Snapshot PoolExceeded the pool usage threshold.xx1x60
MODERATEPool blockadexx2x60
MODERATENo free area in SM.FF2F60
MODERATEXP Thin
Provisioning Pool
Exceeded the pool usage threshold1.xx0x62
MODERATEExceeded the pool usage threshold2.xx1x62
39
