Table 18 SNMP Failure Trap Reference Codes (continued)
Alert LevelDescriptionTrap Reference Code
SIM13SIM23SIM22
SERIOUSA currently used M-VOL has been
suspended because DFW to R-VOL was
prohibited.
x: The CU number
yy: The LDEV number
yy3xDB
SERIOUSA currently used M-VOL has been
suspended because an operation for
suspending an R-VOL was performed.
x: The CU number
yy: The LDEV number
yy4xDB
SERIOUSA currently used M-VOL has been
suspended because an operation for
deleting a pair was performed on an
R-VOL.
x: The CU number
yy: The LDEV number
yy5xDB
SERIOUSA currently used R-VOL has been
suspended because an unrecoverable
failure occurred in the remote copy
connection.
x: The CU number
yy: The LDEV number
yy6xDB
SERIOUSA currently used R-VOL has been
suspended because an unrecoverable
failure occurred in R-VOL.
x: The CU number
yy: The LDEV number
yy7xDB
MODERATEMCU detected a moderate-level SIM of
RCU.
x: The CU number
yy: The LDEV number
yyDxDB
SERIOUSFailure with paired
volumes
MCU detected an acute-level or
serious-level SIM of RCU.
x: The CU number
yy: The LDEV number
yyExDB
SERIOUSThe M-VOL status and the R-VOL status
are not the same.
x: The CU number
yy: The LDEV number
yyFxDB
SERIOUSVolume used as P-VOL has been
suspended (Unable to restore path)
xx0xDC
SERIOUSVolume used as P-VOL has been
suspended (MCU failure detected)
xx1xDC
SERIOUSVolume used as P-VOL has been
suspended (RCU failure detected)
xx2xDC
