HP StorageWorks XP24000/XP20000 SNMP Agent Reference Guide (AE131-96088, May 2011)

Table 18 SNMP Failure Trap Reference Codes (continued)
Alert LevelDescriptionTrap Reference Code
SIM13SIM23SIM22
SERIOUSVirus detected (Virus isolation failed)0xF67F
SERIOUSLicense keyExpirationxxF77F
SERIOUSExceeded the licensed capacityxxF87F
SERIOUSProgram product invalidated by the
expiration of the prerequisite program
product.
xxF97F
SERVICESVPThis is not a failure but a test code. This
code is output only by the SNMP trap.
FFFF7F
SERIOUSFailure with paired
volumes
Pair suspend due to RIO path blockadexx0xD4
SERIOUSPair suspend due to failure detected in
M-VOL
xx1xD4
SERIOUSPair suspend due to failure detected in
R-VOL
xx2xD4
SERIOUSPair suspend due to DFW/DRV CAC off
from R-VOL
xx3xD4
SERIOUSPair suspend due to the suspend report
from R-VOL
xx4xD4
SERIOUSPair suspend due to the Simplex report
from R-VOL
xx5xD4
SERIOUSR-VOL has been suspended because an
unrecoverable failure occurred in the
remote copy connection.
xx6xD4
SERIOUSAbnormal status occurring during ERASE
operation in migration copy
xx8xD4
SERIOUSSuspicion of the pair status failurexxFxD4
SERIOUSFailure with paired
volumes
A currently used M-VOL has been
suspended because an unrecoverable
failure occurred in the remote copy
connection.
x: The CU number
yy: The LDEV number
yy0xDB
SERIOUSA currently used M-VOL has been
suspended because an unrecoverable
failure occurred in an M-VOL or the
remote copy connection.
x: The CU number
yy: The LDEV number
yy1xDB
SERIOUSA currently used M-VOL has been
suspended because an unrecoverable
failure occurred in an R-VOL.
x: The CU number
yy: The LDEV number
yy2xDB
37
