HP StorageWorks XP24000/XP20000 SNMP Agent Reference Guide (AE131-96088, May 2011)

5 SNMP Failure Trap Reference
This chapter shows the alert level, the trap reference code, the description, and the alert level:
• “SNMP Failure Trap Reference Codes” (page 34)
• “SIM List for TrueCopy for Mainframe Errors” (page 40)
The following table shows the alert level, the trap reference code, the description, and the alert
level.
Table 18 SNMP Failure Trap Reference Codes
Alert LevelDescriptionTrap Reference Code
SIM13SIM23SIM22
MODERATEProcessorLCM hard erroryz3x21
MODERATEADP blockadexy7221
MODERATERIO path blockadexy8021
MODERATERemote copy logical path blockade
(notification of failure from extender)
xy8221
SERIOUSLink data transfer errorxy9321
SERIOUSLink data transfer errorxy9421
MODERATEHTP hardware errorxyA021
MODERATEHTP path blockadexyA221
MODERATEHTP blockadexyA321
MODERATEExternal port blockade
x: The CHA package number
y: The number of the port in the package
xyD021
SERVICEExternal device response timeout
x: The CHA package number
y: The number of the port in the package
xyD221
MODERATEProcessor blockadexy7330
MODERATEFM failurexy7530
AcuteCHA PCB blockade
xx=00:Fibre, xx=01:MFibre,
xx=02:Serial
xx=FF:All CHA
xxA030
AcuteDKC blockade00A130
MODERATEProcessor blockadexy7331
MODERATEFM failurexy7531
AcuteDKA PCB blockade00A031
MODERATEDRR blockadexy82CF
MODERATEFCA blockadexy83CF
34 SNMP Failure Trap Reference
