Supported Traps
The following table shows the supported trap types.
Table 11 Extension Trap Types
DescriptionTrapSpecific Trap Code
All operations in a storage system
stopped.
RaidEventUserAcute1
Operation in a component where a
failure occurred stopped.
RaidEventUserSerious2
Partial failure.RaidEventUserModerate3
Minor failure.RaidEventUserService4
MIB Mounting Specifications
The supported MIB mounting specifications are as follows:
• mgmt: OBJECT IDENTIFIER ::= {iso(1) org(3) dod(6) internet(1) 2 }
• mib-2: OBJECT IDENTIFIER ::= {mgmt 1}
An SNMP agent mounts only system groups in mib-2, as shown in the following table.
Table 12 System Groups
Mounted ValueDescriptionName
Fixed value
RAID 600
Name of hardware or OS.sysDescr
{system 1}
Fixed value. See “Object Identifier
System” (page 22).
1.2.6.1.4.1.116.3.11.4.1.1
Object ID indicating the product
identification number.
sysObjectID
{system 2}
Unit: msAn accumulated time from an SNMP
agent.
sysUpTime
{system 3}
Maximum 180 characters in an ASCII
characters string (see Note)
Input by a user from an SNMP setting
window.
A manager who manages an agent
or a contact address.
sysContact
{system 4}
Maximum 180 characters in an ASCII
characters string (see Note)
Input by a user from an SNMP setting
window.
A given name for managing an agent.sysName
{system 5}
Maximum 180 characters in an ASCII
characters string (see Note)
Input by a user from an SNMP setting
window.
An agent setup location.sysLocation
{system 6}
Fixed value
76 (decimal)
Value indicating a service.sysService
{system 7}
