HP StorageWorks XP24000/XP20000 SNMP Agent Reference Guide (AE131-96088, May 2011)

Table 9 Failure Report Trap
DescriptionTypeObject IdentifierName
The product number of the
device that experienced the
failure.
INTEGER1.3.6.1.4.1.116.5.11.4.2.1EventTrapSerialNumber
The device nickname.DisplayString1.3.6.1.4.1.116.5.11.4.2.2EventTrapNickname
The failure referenceDisplayString1.3.6.1.4.1.116.5.11.4.2.3EventTrapREFCODE
The area where the failure
occurred (Note).
OBJECT
IDENTIFIER
1.3.6.1.4.1.116.5.11.4.2.4EventTrapPartsID
Failure occurrence date.DisplayString1.3.6.1.4.1.116.5.11.4.2.5EventTrapDate
Failure occurrence time.DisplayString1.3.6.1.4.1.116.5.11.4.2.6EventTrapTime
Detailed information about
a failure.
DisplayString1.3.6.1.4.1.116.5.11.4.2.7EventTrapDescription
NOTE: For example, the object identifier for a failure in a storage system processor would be
1.3.6.1.4.1.116.5.11.4.1.1.6.1.2.
Standard MIB Specifications
Supported MIB
The following table shows the supported MIBs. If you send a GET request for an object (MIB) that
is not supported, you will receive NoSuchName as a GET RESPONSE.
Table 10 Supported MIBs
Supported?MIB
Supportedsystem groupStandard MIB: MIB-II
Not supportedinterface group
Not supportedat group
Not supportedip group
Not supportedicmp group
Not supportedtcp group
Not supportedudp group
Not supportedegp group
Not supportedsnmp group
SupportedExtension MIB
MIB Access Mode
The access mode for MIB in all communities is read only. If you send a GET request for a SET
operation, you will receive NoSuchName as a GET RESPONSE.
Object Identifier System
An object system supported by SNMP agent is as follows:
22 SNMP Supported MIB
