Table 6 SNMP Information Tab (continued)
DescriptionItem
Enter the IP address of the manager that the SNMP Agent
receives the request from.
• Ipv4 and Ipv6 addresses can be specified for IP
Address. However, if the OS of SVP is Windows XP
and you enter Ipv6 address and select Apply, an error
message is displayed and the Ipv6 address is not set.
• Any IP address having all values set to zero (0) cannot
be specified for Ipv4 and Ipv6.
• The Ipv4 address is specified by entering four (4)
numbers that are separated by periods (.) using a
maximum 3 digits from zero (0) to 255 inclusive (for
example, XXX.XXX.XXX.XXX where X is a number). Enter
the numbers only and do not enter periods.
• The Ipv6 address is specified by entering eight (8)
hexadecimal numbers that are separated colons (:) using
a maximum 4 digits from zero (0) to FFFF inclusive (for
example,
YYYY:YYYY:YYYY:YYYY:YYYY:YYYY:YYYY:YYYY where
Y is a hexadecimal number). Enter the hexadecimal
numbers only and do not enter the colons. The cursor
can be moved between the entry field using the Tab
key.
IP Address text box
Is selected when entering an Ipv4 address. The Ipv4
address can be entered to IP address text box when this
radio box is selected.
Ipv4 radio box
Is selected when entering Ipv6 address. The Ipv6 address
can be entered to IP address text box when this radio box
is selected.
Ipv6 radio box
Adds new IP addresses to the IP Address list box.Set
Allows you to add, delete, or change SNMP trap
information. The registered IP address is the trap destination
for the specified community.
• Each community can have more than one defined IP
address (see “Adding a Community Name” (page 16)
and “Adding Community IP Addresses” (page 18)).
• You can register up to 32 community names and up to
32 IP addresses per community name.
• You can use up to 180 alphanumeric characters for a
community name. You cannot use the following: ", \,
;, :, ,, *, ?, <, >, |, /, ^, &, %, and a space before or
after the community name.
Community & Trap
