Figure 4 SNMP Information Tab
Table 6 SNMP Information Tab
DescriptionItem
The Extension SNMP check box is selected if the SNMP
Agent feature is enabled.
To set the SNMP Agent properties from XP Remote Web
Console computer, select Extension SNMP on SNMP
Information window.
Install
The Manager section allows you to add and delete SNMP
manager information (see “Adding SNMP Manager IP
Addresses” (page 14)).
Manager
Displays the IP addresses of registered SNMP managers
from which the SNMP agent accepts requests. If no
manager is registered, the SNMP agent accepts requests
from all managers. You can register up to 32 managers.
IP Address list box
SNMP Information Tab 11
