11 LUN Security XP Extension function
Attribute operation
user-name,xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,[LSE],Attribute,,Normal end,Seq.=xxxxx
+{CU:LDEV,Attribute,Result}=[{0x00:0x01,0x80,Normal end},{0x00:0x02,0x82,Error(9605-8122)},
{0x00:0x03,0x81,Normal end},{0x00:0x03,0x81,Normal end}],Num. of LDEVs=XXX
[LSE]
LUN Security Extension function
Attribute
Attribute operation
Normal end
The operation has ended normally.
Seq.=xxxxxx
Sequence number of the log entry (000000 to 999999)
Detailed Information
Detailed information for this operation is shown in the following table.
Table 27 Detailed information for Attribute operation
DescriptionItem
The CU number and the LDEV number of the logical volume where the attribute is set.CU:LDEV
The set attribute in hexadecimal. Each bit (0-7) of 1 byte corresponds to the setting
item. 1 is assigned to each bit when the setting is enabled and 0 (zero) is assigned
to each bit when the setting is disabled. Each bit represents the following attributes:
Attribute
Bit 0: Mounting of LEDV (fixed to 1)
Bit 1: Setting of S-VOL Disable
Bit 2: Setting of Zero Read Cap mode
Bit 3: Setting of Invisible mode
Bit 4: Setting of reserve
Bit 5: Fixed to 0 (zero)*
Bit 6: Setting of Read Only attribute*
Bit 7: Setting of Protect attribute*
When 0x88 is output to the attribute, for example, Read/Write attribute is set to the
logical volume to show that the reserve setting has been enabled.
The result of operation.Result
Normal end: Normal end, Error(xxxx-yyyyy): Abnormal end
xxxx: Part code, yyyyy: Error code
