HP StorageWorks XP Audit Log reference guide for the XP12000/XP10000 and SVS 200 (5697-7157, November 2007)

DescriptionItem
The starting cylinder number (CC) and the starting head number (HH) of the cancelled
data.
Start CC-HH
The ending cylinder number (CC) and the ending head number (HH). This number
is output when the ending cylinder and ending head are specified for the cancelled
data.
End CC-HH
The number of logical volumes (for a mainframe system) where the setting information
of Cache Residency cache was cancelled.
Num. of LDEVs
Delete Open DCR operation
user-name,xx,YYYY/MM/DD,HH:MM:SS:xxx, 00:00,[Cache],Delete Open DCR,,Normal end,Seq.=xxxxx
+{CU:LDEV,Start LBA,End LBA}=[{0x00:0x00,XXXXXXXXXXXXXXXX,XXXXXXXXXXXXXXXX},
{0x00:0x00,XXXXXXXXXXXXXXXX,XXXXXXXXXXXXXXXX}],Num. of LDEVs=2
[Cache]
Cache function
Delete Open DCR
Delete Open DCR operation
Normal end
The operation has ended normally.
Seq.=xxxxxx
Sequence number of the log entry (000000 to 999999)
Detailed Information
Detailed information for this operation is shown in the following table.
Table 19 Detailed information for Delete Open DCR operation
DescriptionItem
The CU and LDEV numbers of the logical volume (for an open system) where the
setting information of Cache Residency cache was canceled.
CU:LDEV
The starting LBA number of the cancelled data.Start LBA
The ending LBA number of the cancelled data. This number is output when only
the ending LBA is specified for the cancelled data.
End LBA
The number of logical volumes (for an open system) where Cache Residency cache
was canceled.
Num. of LDEVs
Set M/F DCR operation
user-name,xx,YYYY/MM/DD,HH:MM:SS:xxx, 00:00,[Cache],Set M/F DCR,,Normal end,Seq.=xxxxx
+{CU:LDEV,Mode,Prestaging,Start CC-HH,End CC-HH}=[{0x00:0x00,Bind,No,XXXXXX-XX,XXXXXX-XX},
{0x00:0x00,Priority,Yes,XXXXXX-XX,XXXXXX-XX}],Num. of LDEVs=2
Cache function64
