32 Continuous Access XP - Journal function
Journal-Option operation
user-name,xx,YYYY/MM/DD,HH:MM:SS:xxx, 00:00,[CAXJ],Journal-Option,,Normal end,Seq.=xxxxx
+{JNLG,MetaData Ratio,Extent,Data Overflow Watch(s),Inflow Control,Copy Pace,
Path Watch Time,Forward Path Watch Time,Use of Cache,Speed of Line(Mbps),
Delta resync Failure,Result}=
-{0x01,32,32,20,No,150,30(min.),Yes,Not Use,256,Entire,Normal end},(snip),
{0x02,32,32,20,No,150,12(hour),No,Use,256,Entire,Normal end},Num. of JNL Grps=3
[CAXJ]
Continuous Access Journal function
Journal-Option
Journal-Option operation
Normal end
The operation has ended normally.
Seq.=xxxxxx
Sequence number of the log entry (000000 to 999999)
Detailed Information
Detailed information for this operation is shown in the following table.
Table 231 Detailed information for Journal-Option operation
DescriptionItem
The journal group number.JNLG
The ratio of the metadata to the journal data. When the ratio is 1:32, the
number for MetaData Ratio is 32.
MetaData Ratio
The number of extents.Extent
The overflow watch time of the metadata or journal data. The unit is second.Data Overflow Watch(s)
Indicates whether inflow control is executed or not.Inflow Control
Yes: Controlled, No: Not controlled
The speed of initial copy. 150: Low speed, 500: Medium speed, 1500: High
speed
Copy Pace
The path blockade watch period set. The unit is minute.Path Blockade Watch(m)
Indicates the path blockade watch period set. The unit is minute. The unit is
minutes (min), hours (hour) or days (day). Example: 30(min) indicates 30
minutes.
Path Watch Time(m)
