HP StorageWorks XP Audit Log reference guide for the XP12000/XP10000 and SVS 200 (5697-7157, November 2007)

Change CTG Option operation
user-name,xx,YYYY/MM/DD,HH:MM:SS:xxx, 00:00,[TC z/OS(R)], Change CTG Option,,Normal end,
Seq.=xxxxx
+{CTG, Offloading(min.),Inflow Control,Copy Pending(min.),RCU Ready(min.),Timer Type}=
{0x00,090,Enable,05,05,System}
[TC z/OS]
TrueCopy z/OS function (for IBM z/OS)
Change CTG Option
Change Consistency Group (CTG) Option operation
Normal end
The operation has ended normally.
Seq.=xxxxxx
Sequence number of the log entry (000000 to 999999)
Detailed Information
Detailed information for this operation is shown in the following table.
Table 222 Detailed information for Change CTG Option operation
DescriptionItem
The consistency group number of the consistency group (CT group) that the
option is changed.
CTG
The value set to the offloading timer of the sidefile. The unit is minute.Offloading(min.)
Indicates whether the inflow control to the cache is enabled or disabled.Inflow Control
Enable: Setting is enabled, Disable: Setting is disabled
The setting value for Time Out (Copy Pending). The unit is minute. When Time
Out (Copy Pending) is set to 0 (zero), None is output.
Copy Pending(min.)
The setting value for Time Out (RCU ready). The unit is minute. When Time Out
(RCU ready) is set to 0 (zero), None is output.
RCU Ready(min.)
The timer type set.Timer Type
System: System timer, Local: Local timer, None: No timer (system timer)
Change Option operation
user-name,xx,YYYY/MM/DD,HH:MM:SS:xxx, 00:00,[TC z/OS(R)],Change Option,,Normal end,
Seq.=xxxxxx
+{ Max Initial Copy,Path Blockade Watch(s),Path Blockade SIM Watch(s) }={128,45,70}
+{CU,Service SIM,PPRC Support,SCP Delay Time(s)}=
-{0x00,Not Report,Yes,600},{0x01,Not Report,Yes,600},{0x02,Not Report,Yes,600},
{0x03,Not Report,Yes,600},{0x04,Not Report,Yes,600},(snip)
-(snip), Num.of CUs=64
[TC z/OS]
TrueCopy (TC) z/OS function240
