DescriptionItem
Indicates whether to report the remote copy-related SIM.Service SIM
Report, Not Report
Indicates whether the host supports PPRC.PPRC Support
Yes: support, No: not support
The SCP delay time when the pair is suspended. The unit is second.SCP Delay Time(s)
The number of CUs set.Num. of CUs
Change Pair Option operation
user-name,xx,YYYY/MM/DD,HH:MM:SS:xxx, 00:00,[CAXP],Change Pair Option,,Normal end,Seq.=xxxxxx
+{P-VOL(Port-G-ID-LUN),Fence Level, Error Level,Result}=
-{1A-0x00-0x000,Never,Group,Normal End},{1A-0x00-0x001,Never,Group,Normal End},
{1A-0x00-0x002,Never,Group,Normal End},(snip)
-(snip), Num. of Pairs=xx
[CAXP]
Continuous Access XP function
Change Pair Option
Change Pair Option operation
Normal end
The operation has ended normally.
Seq.=xxxxxx
Sequence number of the log entry (000000 to 999999)
Detailed Information
Detailed information for this operation is shown in the following table.
Table 213 Detailed information for Change Pair Option operation
DescriptionItem
The port number, host group number and LUN of the primary volume where the
pair option is changed sequentially.
P-VOL(Port-G-ID-LUN)
The changed fence level (the condition that MCU rejects Write to the primary
volume).
Fence Level
Never: No condition, Data: S-VOL data, Status: S-VOL status
The error level changed (handling in case of trouble).Error Level
This value is output when the pair option of the asynchronous pair is changed
only.Group: Group (suspended by consistency group),
LU: LU (appropriate LU only is suspended)
The result of operation.Result
Normal end: Normal end, Error(xxxx-yyyyy): Abnormal end
Continuous Access XP function230
