Detailed information for this operation is shown in the following table.
Table 173 Detailed information for Change RCU Option operation
DescriptionItem
Indicates a serial number of the RCU device where the RCU option setting is
changed.
S/N
The RCU path group ID where the RCU optional setting is changed. When the path
group ID is default setting, Default is output.
Path Gr. ID
The controller ID of the RCU where the optional setting is changed.Controller ID
Indicates SSID of the RCU where the optional setting is changed.SSID
The minimum number of paths after change.Min. Path
The value of RIO MIH (Remote I/O Missing Interrupt Handler) timer (wait time until
data copy from MCU to RCU is completed). The unit represents seconds.
MIH Time(s)
The round-trip response time (delay time for round-trip remote I/O) after change.
The unit is in milliseconds. This value is output when Continuous Access XP or
TrueCopy for z/OS is used.
Round Trip Time(ms)
The incident of RCU after change. This value is output only when TrueCopy for
z/OS is used.
Incident
“only to RCU host” or “to any host” is output.
Indicates whether CGROUP (FREEZE/RUN) PPRC TSO command support is enabled
or disabled. This value is output only when TrueCopy for z/OS is used.
FREEZE
Enable or Disable is output.
The number of port pairs changed.Num. of Port Pairs
Delete Path operation
Example 1 (CU Free is used)
user-name,xx,YYYY/MM/DD,HH:MM:SS:xxx, 00:00,[RCU],Delete Path,,Normal end,Seq.=xxxxx
+{S/N,Path Gr. ID,Controller ID}={99999,Default,4}
++{MCU Port,RCU Port}=[{1E,3E},{5E,7E},{1F,3F},{5F,7F},{1G,3G},{5G,7G},{1H,3H},{5H,7H}],
Num. of Port Pairs=8
Example 2 (CU Free is not used)
user-name,xx,YYYY/MM/DD,HH:MM:SS:xxx, 00:00,[RCU],Delete Path,,Normal end,Seq.=xxxxx
+{S/N,SSID,Controller ID}={99999,0x0004,4}
++{MCU Port,RCU Port}=[{1E,3E},{5E,7E},{1F,3F},{5F,7F},{1G,3G},{5G,7G},{1H,3H},{5H,7H}],
Num. of Port Pairs=8
[RCU]
Remote Control Unit function
Delete Path
Delete Path operation
Normal end
