DescriptionItem
The setting status whether to execute authentication by port.Switch
Disable: Do not authenticate, Enable: Authenticate
Not used. (fixed to 0)DH Group
The setting status of authentication method.Auth
bi-directional: bi-directional authentication, unidirectional: unidirectional
authentication
The user name of the port.UserName
The number of ports where authentication parameter has been set.Num. of Ports
Set FCSP Target operation
user-name,xx,YYYY/MM/DD,HH:MM:SS:xxx, 00:00,[LUNM],Set FCSP Target,,Normal end,Seq.=xxxxx
+{Port,HostGrpID,Switch,DH Group,UserName}=[{1E,0x01,Enable,0,1111111111111111},
{3E,0x01,Disable,0,2222222222222222}],Num. of Grps=2
[LUNM]
LUN Manager function
Set FCSP Target
Set Fibre-Channel Security Protocol (FCSP) Target operation
Normal end
The operation has ended normally.
Seq.=xxxxxx
Sequence number of the log entry (000000 to 999999)
Detailed Information
Detailed information for this operation is shown in the following table.
Table 138 Detailed information for Set FCSP Target operation
DescriptionItem
The name of the port which includes the host group where authentication
parameter has been set.
Port
The number of the host group where authentication has been set.HostGrpID
The setting status whether to execute authentication by host group.Switch
Disable: Do not authenticate, Enable: Authenticate
Not used. (fixed to 0)DH Group
The user name of the host group.UserName
The number of host groups where authentication parameter has been set.Num. of Grps
XP Audit Log reference guide 157
